Σ-Δ high-precision analog-to-digital conversion, which can process signals in the range of -16~18mV
No need to re-calibrate the table, high precision and good consistency
DC interface has anti-reverse connection, anti-short circuit protection
Strong anti-interference ability, wide applicable environment
AC and DC dual-purpose, standard battery
7-digit 0.8-inch LED display, 3-step battery level indication
Zero tracking range and zero (boot/manual) range can be set separately
With two-point linear correction function, two kinds of compensation calibration methods
Large storage capacity, can store 1001 groups of weighing records, 1000 groups of car numbers and tare weight, 201 cargo numbers
Can print weighing orders such as horizontal and vertical links, and can print a variety of statistical reports
Equipped with RS232 communication port (optional RS422/RS485), equipped with current ring large screen communication port, equipped with standard parallel printing port, support for specified models of thermal micro printers
A9P built-in needle type micro-punch
Conversion principle: Σ-Δ type A/D
Input signal range: -16 mV ~ 18 mV
Conversion speed: 10 times/sec
A/D conversion resolution code: 1 million codes
Bridge power supply: DC, 10V, can be connected to 8 350Ω or 16 700Ω sensors
Sensor connection mode: 6-wire type, long line automatic compensation
Index value: 1/2/5/10/20/50/100 optional
Clock: Can display year/month/day, hour/minute/second, automatic leap year, leap month.
Transmission mode: 20mA current loop
Baud rate: 600
Transmission distance: ≤2000m
Standard parallel output interface
Data storage: can store 1000 car numbers and tare weight, 201 cargo numbers, 1001 groups of weighing records
AC power supply: AC 220V (-15%~+10%); 50Hz（-2%~+2%）
DC power supply: DC 12V/7AH battery (external)
