AC and DC dual-use
With good electromagnetic compatibility performance and super electrostatic protection ability
With expansion interface, optional expansion function module
Print the communication isolation module
Switching output module
4 ~ 20mA module
Can connect a number of digital sensors of YAOHUA protocol
Automatic/semi-automatic/manual angle difference correction
Digital sensor communication address modification function
Single sensor data viewing function
Automatic switching of the second-gear index value
Non-linear correction function and calibration error correction function
Timed shutdown function
Weighing record storage/inspection/deletion/power failure protection
Equipped with RS-232C/RS485 communication port
Equipped with a large screen communication port of the current ring; Equipped with a standard parallel printing interface
Can store 1000 groups of vehicle license plate number and tare weight, 201 groups of cargo number, can store 1001 groups of weighing records
Can backup and restore various parameters in the instrument, reliable and practical
Digital sensor connection
Connection mode: RS485 mode, four or six wire compatible
Communication distance: about 1000 meters
Number of connections: 1 to 16
Sensor communication protocol: Shanghai YWIES
Sensor power supply: DC 10V, 0.8A(Max)
Large-screen interface
Signal: 20mA current loop, serial output
Baud rate: 600, transmission distance: ≤2000 meters
Print interface
Wide line printer can be connected: LQ-300K, KX-P1131, KX-P1121
