channel steel
Shanghai Yaohua A39E
3.5×2000×3000mm
3t
| Quantity: | |
|---|---|
| Project name | Technical parameters |
| Sensor | Ke Li 3tons tumbler |
| Bottm shelf | 3.5×50×100mm Square tube |
| Branches | 5.5×75×195mm Square tube |
| Seamless pipe | 12×102×1360mm Round tube |
| Base frame weighing | Two sides plus fixed support legs |
| Lifting height | 3m |
| Tire | 4.00-8 |
| Guardrail | Height 0.9m 40*40 30*30 Square tube |
| Door | Width1m,Double push and pull , wrapped in tin around |
| Door track | Hanging tepy |
| Steering system | Traction Turntable type |
| Outriggers | Hydraulic cylinder lifting |
| Traction mode | External traction |
| Wheelbase | 2150mm |
| Hydraulic cylinder | 80cylinders 2sticks |
| Minimum operating height | 1.20m |
| Shaft pin wheels | 45#steel Quenching and tempering process |
| Power unit | 380v 4KW Hydraulic oil station Double layer explosion proof |
| Solenoid valve | 220V DSG-02-3C60-DL |
| Upper limit control mode | Limit switch |
| Control mode | Handle control |
| Control contactor | 20A 380V Delixi |
| Hydraulic Oil | 46# Anti-Wear Hydraulic Oil |
| Stroke switch | LXK3 Delixi LXK3 |
| Distribution box | 400×500mm Outdoor box |
| Mode of operation | Remote handle control |
| Lug and arm | Plate thickness14mm |
| Finish paint | Electrostatic spraying |
| Additional | 500m lift remote control AC 380V |
